Application: T-shirt bags, shopping bags, garbage bags, mattress cover, laundry bags etc
Suitable material: HDPE / MDPE / HDPE+LLDPE
Film layer: 1 layer
Screw L/D ratio: 30:1
Motor direct connection type gearbox
PID+SCR temperature controller
ABB or HITACHI inverter
Gusset device
Items/Models | H25/300 | H35/500 | H45/650 | H55/800 | H65/1100 | H80/1500 |
|---|---|---|---|---|---|---|
| Screw Diameter (mm) | 25 | 35 | 45 | 55 | 65 | 80 |
| Film Width (mm) | 120-200 | 150-400 | 200-550 | 300-700 | 500-1000 | 700-1350 |
| Output (kg/hr) | 5-12 | 15-28 | 25-45 | 35-45 | 50-100 | 80-140 |
| Film Thickness (mm) | 0.006-0.08 , depending on the material and film size | |||||
| Main Motor (HP) | 5 | 10 | 20 | 30 | 50 | |
Matila is famous for manufacturing film blowing machines. Besides,it has 40 years experience in manufacture and design the Blown Film Machine.In order to control the quality when the film is blown, Matila (Jiangsu) has its own design and manufacture team of die head.Furthermore, Matila (Jiangsu) controls the manufactured quality at all times, it has lathe machines, milling machines and drilling machines.It already has extensive experience in mass production and customized the Blown Film Die Head.
